Model Number Table:
| Model | MT-52521 | MT-52531 | MT-52551 |
| Interface Cable | RS-232 | Keyboard | USB |
Note: MT-52521 (RS-232 wedge) needs an external power adapter to drive the RS-232 interface. The external power adapter is optional.
Specification:
| Function | MT-52521 | MT-52531 | MT-52551 |
|
OPTICAL |
|||
| Object/Image Path | 38mm | ||
| Resolution | 0.127mm (PCS = 90%) | ||
| Receiving Device | Photo Sensor | ||
| Light Source | 650 ~ 660nm visible Red LED | ||
| LED Array Type | 2 LED Lamp | ||
|
MECHANICAL / ELECTRICAL |
|||
| Housing Material | ABS | ||
| Shape | PEN Scanner Type | ||
| Connector & Interface Format | RS-232 | Keyboard | USB |
| Dimension | 150 x 29.6 x 22 mm (L x W x H) | ||
| Supply Voltage | 5VDC ± 10% | ||
| Surge Power on Current | < 500mA | ||
| Working Current | 65mA ± 10mA | 45mA ± 10mA | 60mA ± 10mA |
| Noise Rejection | Max. 100mV Peak to Peak, 10KHz to 100KHz | ||
| Process Unit | AMIC A8351601F | ||
| Cable Length | 100 cm | ||
| Weight | 100g (incl. cable) | ||
|
SYSTEM & SOFTWARE |
|||
| Operation Mode | Continuous Scan Mode | ||
| Symbologies |
UPC-A / UPC-E, EAN-8 / EAN-13, Interleave 2 of 5, Matrix 2 of 5, Code 11, Code 93, Code 32, Code 39, Full ASCII Code 39, Interleave 2 of 5, China Postal Code (Toshiba Code), MSI Code, UK Plessy Code, Codabar, Code 128 |
||
| Safety Approval | FCC Class A, CE | ||
| ESD Protection | Functional after 8KV discharge | ||
| Vibration | Withstands 5G Peak from 20 to 300 Hz | ||
| Mechanical Shock | Operational after 20 drops 1.8m to concrete | ||
|
PERFORMANCE |
|||
| Scan Rate | 100mm
~ 600mm / Sec. PCS = 0.9 (15 mil code) |
||
| Pitch Angle | 0.2mm
to 0.39mm Code, PCS = 0.9 45° to 85°, 95° to 135° |
||
| 0.127mm
to 0.15mm Code, PCS = 0.9 60° to 85°, 120° to 135° |
|||
| Printing Contrast Scale | 0.6 PCS | ||
|
ENVIRONMENTAL |
|||
| Operating Temperature | 0°C ~ 50°C (32°F ~ 122°F) | ||
| Storage Temperature | -20°C ~ 60°C (-4°F ~ 140°F) | ||
| Relative Humidity | 20% RH ~ 85% RH | ||
